APC Easy UPS SRV 1000VA 230V
Key Features Output power capacity – 800Watts / 1.0kVA Output Connections – (3) IEC 320 C13 (Battery Backup) Nominal Output Voltage – 230V Nominal Input Voltage – 230V Input Connections – IEC-320 C14 Cord Length – 1.5meters
Description
APC Easy UPS SRV 1000VA 230V
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
Includes: Basic UPS signalling RS-232 cable, CD with software, USB cable, User Manual
Additional information
| Weight | 10.6 kg |
|---|---|
| Color | |
| Max Configurable Power (Watts) | 800Watts / 1.0kVA |
| Output Voltage Note | Configurable for 220 : 230 or 240 nominal output voltage |
| Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz |
| Other Output Voltages | 220, 240 |
| Load Crest Factor | 3 : 1 |
| Topology | Double Conversion Online |
| Waveform type | Sine wave |
| Bypass | Internal Bypass (Automatic and Manual) |
| Input frequency | 40 – 70 Hz |
| Input voltage range for main operations | 160 – 280V |
| Input voltage adjustable range for mains operation | 110 – 285 (half load)V |
| Number of Power Cords | 1 |
| Efficiency at Full Load | 88.0 % |
| Other Input Voltages | 220, 240 |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Included Battery Modules | 1 |
| Typical recharge time | 4hour(s) |
| Battery Charge Power (Watts) | 38Watts |
| Battery Volt-Amp-Hour Capacity | 152 |
| Interface Port(s) | DB-9 RS-232, USB |
| Control panel | Multi-function LCD status and control console |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Emergency Power Off (EPO) | – |
| Available SmartSlot™ Interface Quantity | 1 |
| Surge energy rating | 600Joules |
